Zain Fittings, located in Surabaya, Indonesia, has earned a solid reputation as a reliable manufacturer and supplier of top-notch Nickel Alloy 200 Pipe Fittings. These fittings are celebrated for their impressive performance, precise engineering, and remarkable durability, making them perfect for tough industrial settings. Zain Fittings is dedicated to providing products that adhere to international standards, ensuring they offer high corrosion resistance, strength, and reliability. With cutting-edge manufacturing capabilities and a strong focus on customer needs, the company serves a variety of sectors, including chemical processing, marine engineering, power generation, and petrochemicals, offering tailored Nickel Alloy 200 Pipe Fittings to meet unique operational demands.
| Specifications | ASTM B366 / ASME SB366, ASTM B366 UNS N02200, ASME SB366 UNS N02200 | |
|---|---|---|
| UNS N02200 Pipe Fittings size | Alloy 200 Seamless Butt Weld Fittings: 1/2″ – 10″ Alloy 200 Welded Butt Weld Fittings: 1/2″ – 48″ | |
| Nickel Alloy 200 Pipe Fittings Standards | ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, BS4504 , BS4504, BS1560, BS10 | |
| ASTM B366 UNS N02200 Fittings Available Thickness | Schedule 5s, 10s, 40s, 80s, 10, 20, 40, STD, 60, 80, XS, 100, 120, 140, 160, XXS available with NACE MR 01-75 | |
| ASTM B366 200 Buttweld fitting Main Types | Seamless / Welded / Fabricated | |
| Nickel Alloy Ni200 Fittings Thread | NPT , BSPT, BSPP | |
| 2.4066 Nickel Fittings Type | DN15-DN1200 | |
| End | Threaded, Welding, JIC | |
| Hydraulic Tube Fittings Pressure Rating |
| |
| Connection | Welding | |
| UNS 2200 Buttweld Fitting Test Certificates | EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc | |
| Application |
| |
| Material Test Certificates (MTC) as per EN 10204 3.1 and EN 10204 3.2, Test Certificates certifying NACE MR0103, NACE MR0175 | ||
Nickel Alloy 200 Pipe Fittings are primarily made of nickel (at least 99.2%), along with trace amounts of iron, manganese, copper, carbon, and silicon. This commercially pure wrought nickel alloy boasts exceptional corrosion resistance in alkaline and neutral or reducing environments. It has a tensile strength of around 380 MPa, a yield strength of 105 MPa, and an elongation of about 40%. Nickel Alloy 200 retains excellent mechanical properties even at high temperatures, along with superior thermal and electrical conductivity, toughness, and formability, making it ideal for challenging industrial applications.
| Nickel 200 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| 99.0 min | 0.15 max | – | 0.35 max | 0.1 max | 0.4 max | – | 0.01 max | 0.25 max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 g/cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
Zain Fittings is a leading supplier of Nickel Alloy 200 Pipe Fittings in Jakarta, Indonesia. We offer an extensive range of Nickel Alloy 200 Pipe Fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WERKSTOFF NR. | AFNOR | EN | JIS | BS | GOST |
| Nickel 200 | N02200 | 2.4066 | N-100M | Ni 99.2 | NW 2200 | NA 11 | НП-2 |
Nickel Alloy 200 Pipe Fittings from Zain Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
Nickel Alloy 200 pipe fittings offer excellent corrosion resistance, particularly in alkaline environments, and are highly resistant to corrosion from alkalis, acids, and other corrosive substances. These fittings provide excellent strength, ductility, and formability, making them ideal for high-pressure applications. They also exhibit good weldability and ease of fabrication, ensuring reliable and durable connections. Nickel Alloy 200 is highly resistant to embrittlement and cracking, making it suitable for various industries, including chemical processing, marine, and aerospace, where high resistance to corrosion and extreme temperatures is required.
Yes, custom sizes for Nickel Alloy 200 Pipe Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.
These Nickel Alloy 200 Pipe Fittings are extensively utilized in industries that demand outstanding corrosion and heat resistance. They are perfect for equipment in chemical and food processing, marine systems, power generation units, and synthetic fiber production. These fittings excel in caustic soda production, alkali handling, and high-temperature environments. Additionally, they find applications in pressure vessels, condensers, heat exchangers, and electronic components due to their thermal stability and conductivity. Their strength, purity, and resistance to various chemical agents make them suitable for both industrial and marine uses.
