Zain Fittings, a leading manufacturer and supplier based in Jakarta, Indonesia, specializes in providing high-quality industrial fittings for a wide range of applications. Our 45° Long Radius and 45° Short Radius Elbows are engineered to offer smooth, efficient flow control while accommodating both compact and large piping systems. Made from durable materials like stainless steel and alloys, these elbows ensure long-lasting performance and corrosion resistance. Used in industries such as oil and gas, HVAC, and chemical processing, Zain Fittings delivers reliable and efficient solutions.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Seamless 45° Long Radius Elbow Size: 1/2″~24″
ERW / Welded / Fabricated 45° Long Radius Elbow Size: 1/2″ (15 NB) to 48″ (1200NB)
Form: 45° Long Radius Elbow
Zain Fittings is a reputable manufacturer and supplier of top-notch **45° Long Radius Elbow** and **45° Short Radius Elbow**, proudly based in Jakarta, Indonesia. Known for our commitment to precision engineering and dependable service, we provide pipe fittings that adhere to global standards like ASME B16.9 and ASTM specifications. These elbows are expertly designed to efficiently redirect flow in piping systems and find extensive use in industries such as oil and gas, chemicals, power generation, water treatment, and marine applications. We offer a variety of materials, including stainless steel, carbon steel, and alloy steel, with options for custom sizes and pressure ratings available upon request.
Stainless Steel 45° Long Radius Elbow : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel 45° Long Radius Elbow : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex 45° Long Radius Elbow : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy 45° Long Radius Elbow : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel 45° Long Radius Elbow : ASTM A420 WPL3, A420 WPL6
The 45° Long Radius Elbow features a center-to-end distance that is 1.5 times the nominal pipe diameter, promoting smoother flow and reducing pressure drop—perfect for situations where space and flow efficiency are crucial. On the other hand, the 45° Short Radius Elbow has a tighter turn, with a center-to-end distance equal to the pipe diameter, making it ideal for compact installations where space is at a premium but high-pressure resistance is still necessary. Both types are crafted to ensure precise dimensions, corrosion resistance, and a long lifespan, even in challenging operating conditions.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
These elbows play a vital role in piping systems, allowing for a change in flow direction at a 45-degree angle. The long radius version is often favored in process piping to minimize turbulence and pressure loss, while the short radius variant is typically used in confined spaces, such as skid-mounted systems or high-pressure applications, where a compact design is essential. Their sturdy construction, versatility, and compatibility with various welding and threading techniques make them the perfect choice for a wide range of applications.
Yes, custom sizes for 45 Deg Long Redius Elbow and 45 Deg Short Redius Elbow are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.
| NPS | O.D. D | 90 degrees Long Radius Center-to-End A | 45 degrees Long Radius Center-to-End B | 90 degrees 3D Center-to-End A | 45 degrees 3D Center-to-End B |
| 1/2 | 21.3 | 38 | 16 | – | – |
| 3/4 | 26.7 | 38 | 19 | 57 | 24 |
| 1 | 33.4 | 38 | 22 | 76 | 31 |
| 1 ¼ | 42.2 | 48 | 25 | 95 | 39 |
| 1 ½ | 48.3 | 57 | 29 | 114 | 47 |
| 2 | 60.3 | 76 | 35 | 152 | 63 |
| 2 ½ | 73 | 95 | 44 | 190 | 79 |
| 3 | 88.9 | 114 | 51 | 229 | 95 |
| 3 ½ | 101.6 | 133 | 57 | 267 | 111 |
| 4 | 114.3 | 152 | 64 | 305 | 127 |
| 5 | 141.3 | 190 | 79 | 381 | 157 |
| 6 | 168.3 | 229 | 95 | 457 | 189 |
| 8 | 219.1 | 305 | 127 | 610 | 252 |
| 10 | 273 | 381 | 159 | 762 | 316 |
| 12 | 323.8 | 457 | 190 | 914 | 378 |
| 14 | 355.6 | 533 | 222 | 1067 | 441 |
| 16 | 406.4 | 610 | 254 | 1219 | 505 |
| 18 | 457 | 686 | 286 | 1372 | 568 |
| 20 | 508 | 762 | 318 | 1524 | 632 |
| 22 | 559 | 838 | 343 | 1676 | 694 |
| 24 | 610 | 914 | 381 | 1829 | 757 |
| 26 | 660 | 991 | 406 | 1981 | 821 |
| 28 | 711 | 1067 | 438 | 2134 | 883 |
| 30 | 762 | 1143 | 470 | 2286 | 964 |
| 32 | 813 | 1219 | 502 | 2438 | 1010 |
| 34 | 864 | 1295 | 533 | 2591 | 1073 |
| 36 | 914 | 1372 | 565 | 2743 | 1135 |
| 38 | 965 | 1448 | 600 | 2896 | 1200 |
| 40 | 1016 | 1524 | 632 | 3048 | 1264 |
| 42 | 1067 | 1600 | 660 | 3200 | 1326 |
| 44 | 1118 | 1676 | 695 | 3353 | 1389 |
| 46 | 1168 | 1753 | 727 | 3505 | 1453 |
| 48 | 1219 | 1829 | 759 | 3658 | 1516 |
45° Long Radius and 45° Short Radius Elbows are widely used across various industries for efficient fluid and gas flow control. The Long Radius Elbow is ideal for large-scale systems, such as in oil and gas pipelines, chemical processing, and HVAC systems, where minimal pressure drop and smooth flow are critical. The Short Radius Elbow, due to its compact design, is used in tight spaces, such as in smaller piping systems, plumbing, and fuel lines, where quick directional changes are required while maintaining structural integrity. Both offer excellent durability and corrosion resistance.
