Zain Fittings stands out as a top-notch manufacturer and supplier of Long Radius and Piggable Bends, proudly based in Surabaya, Indonesia. This company is all about crafting high-quality pipe bends that excel in flow efficiency, strength, and durability for industrial piping systems. Long radius bends feature a gentler curve, which helps to minimize pressure drops and turbulence, while piggable bends are specifically designed to let cleaning pigs or inspection devices glide through pipelines without a hitch. Zain Fittings provides these bends in a variety of materials, including carbon steel, stainless steel, alloy steel, and duplex or super duplex steel, catering to industries like oil and gas, petrochemical, chemical processing, and power generation.
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Size: 1/2″–60″
Form: Long Radius Bend, Induction Bend, With R=3D, 5D, 6D, 8D, 10D & Customized Bend
Standard – ANSI/ASME :ASTM A403 / ASME SA403, ANSI B16.9, ASME B16.25, ASME B16.28, MSS SP-43.
DIN : DIN2605, DIN2615, DIN2616, DIN2617, DIN28011
EN : EN10253-1, EN10253-2
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Type : Seamless / ERW / Welded / Fabricated
Size Range : 2″NB TO 18″ NB ANSI B 16.9 IN
Form: Piggable Bends
When it comes to manufacturing Long Radius and Piggable Bends, precision is key. These bends are crafted to exact specifications, ensuring smooth flow, minimal turbulence, and consistent pressure throughout the pipeline. Made from top-quality materials, they boast impressive tensile strength, yield strength, and corrosion resistance. You can find them in seamless, forged, or buttweld constructions, all of which guarantee superior mechanical properties, precise dimensions, and long-lasting reliability even in high-pressure, high-temperature, and chemically aggressive environments.
Zain Fittings is a leading supplier of Long Redius and Piggable Bend in Jakarta, Indonesia. We offer an extensive range of Collar, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Long Redius and Piggable Bend from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Long Radius and Piggable Bends offer several key advantages, including smooth internal surfaces that minimize flow turbulence and reduce pressure drops in pipeline systems. Their gentle curves ensure a more efficient flow of fluids, enhancing overall system performance. The durability and resistance to corrosion, heat, and pressure, especially in materials like stainless steel and alloy steel, extend the lifespan of the fittings. Additionally, their ability to accommodate pigs (cleaning tools) ensures easier maintenance and reduces the risk of blockages, making them ideal for complex and demanding piping applications.
Yes, custom sizes for Long Redius and Piggable Bend are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.
Stainless Steel Long Radius Bend : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Long Radius Bend : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel Long Radius Bend : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel Long Radius Bend : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex Long Radius Bend : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy Long Radius Bend : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel Long Radius Bend : ASTM A420 WPL3, A420 WPL6
Stainless Steel Piggable Bend : ASTM A403 WP316/316L, ASTM A403 WP304/304L, ASTM A182 F316L, 304L, DIN 1.4301, DIN1.4306, DIN 1.4401, DIN 1.4404, 304H, 309, 310, 316, 316L, 317L, 321, 347, 904L
Carbon Steel Piggable Bend : ASTM A234, ASME SA234 WPB , WPBW, WPHY 42, WPHY 46, WPHY 52, WPH 60, WPHY 65 & WPHY 70.
Alloy Steel Piggable Bend : ASTM A234, ASME SA234 WP1 / WP5 / WP9 / WP11 / WP22 / WP91
Duplex Steel Piggable Bend : ASTM A815, ASME SA815 UNS No S31803, S32205
Super Duplex Piggable Bend : ASTM A815, ASME SA815 UNS No S32750, S32950
Nickel Alloy Piggable Bend : ASTM B336, ASME SB336, Nickel 200 (UNS No. No2200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020), Titanium (Grade I & II), Cupro-Nickel 70/30, CuNi10Fe1Mn, CuNi30Mn1Fe.
Low Temperature Carbon Steel Piggable Bend : ASTM A420 WPL3, A420 WPL6
| Nominal PN (MPa) | DN | Thread D | Pipe Specification DH×s | L1 | L2 | L3 (Not less than) | L (Not less than) | R |
| 32.0 | 175 | M240×6 | 245×36 | 120 | 130 | 360 | 1095 | 735 |
| 200 | M265×6 | 273×40 | 130 | 140 | 390 | 1209 | 819 | |
| 225 | M320×6 | 325×50 | 175 | 185 | 525 | 1500 | 975 | |
| 250 | M350×6 | 355.6×55 | 195 | 205 | 580 | 1650 | 1070 | |
| 22.0 | 175 | M215×6 | 219×24 | 100 | 110 | 300 | 957 | 657 |
| 200 | M240×6 | 245×26 | 110 | 120 | 330 | 1065 | 735 | |
| 225 | M265×6 | 273×29 | 115 | 125 | 345 | 1164 | 819 | |
| 250 | M295×6 | 299×32 | 120 | 130 | 360 | 1257 | 897 |
These bends are essential in industries that need efficient directional changes in pipelines while keeping flow efficiency intact and allowing for easy cleaning or inspection. They’re perfect for oil and gas pipelines, chemical and petrochemical plants, power generation facilities, and water treatment systems. By reducing wear and minimizing pressure drops, they also facilitate the safe passage of pigs for inspection or maintenance. Plus, they find their place in marine, pharmaceutical, and food processing industries, delivering reliable, durable, and corrosion-resistant performance in even the most demanding pipeline applications.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
