Zain Fittings, a well-respected manufacturer and supplier located in Surabaya, Indonesia, has built a solid reputation for delivering top-notch Inconel 617 Pipe Fittings to clients in Midland, UK. With a strong focus on precision engineering and quality, this company produces fittings that truly shine in extreme conditions. Designed to endure high temperatures, oxidation, and corrosion, these fittings are perfect for industries that demand the best. Zain Fittings is dedicated to meeting international standards and offers a diverse selection of Inconel 617 Pipe Fittings that provide outstanding durability, reliability, and performance across various industrial applications in the UK and beyond.
Specifications ASTM B366 / ASME SB366
Dimensions ASME/ANSI B16.9, ASME B16.28, MSS-SP-43, MSS SP-79
Size 1/8” NB TO 48” NB. (Seamless & 100% X-Ray Welded, Fabricated)
Type Seamless / Welded / Fabricated
Bending Radius R=1D, 2D, 3D, 5D, 6D, 8D, 10D or Custom
Thickness Sch 5s, Sch 10s, Sch 40s, Sch 80s, Sch 160s, Sch XXS
Grade Inconel 617 UNS (N06617), DIN (2.4663)
Inconel 617 Pipe Fittings are primarily made from nickel, chromium, cobalt, and molybdenum, which gives them remarkable strength and oxidation resistance at elevated temperatures. The alloy boasts impressive mechanical properties, including high tensile and yield strength, excellent creep resistance, and exceptional metallurgical stability. With its remarkable resistance to carburization and corrosion in harsh environments, Inconel 617 guarantees long-lasting performance and structural integrity. These qualities make it an ideal choice for applications that require durability and thermal stability in challenging industrial settings.
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
Zain Fittings is a leading supplier of Inconel 617 Pipe Fittings in Jakarta, Indonesia. We offer an extensive range of Monel 400 fittings, renowned for their excellent corrosion resistance and high strength, which makes them perfect for demanding industrial applications like chemical processing, marine environments, and high-temperature systems. With a commitment to quality and reliable delivery, we ensure our clients receive top-tier products tailored to meet the specific needs of various industries.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| STANDARD | UNS | WNR. |
| Alloy 617 | N06617 | 2.4663 |
Inconel 617 Pipe Fittings from Zain Fittings offer exceptional corrosion resistance, especially in seawater and harsh environments. They are known for their high strength, durability, and resistance to pitting and crevice corrosion, ensuring long-lasting performance. We provide precise manufacturing, quality control, and reliable service for diverse industrial applications.
| NOMINAL PIPE SIZE | ALL FITTINGS | ALL FITTINGS | 180 DEG RETURN BENDS | REDUCERS | ELBOWS AND TEES | 180 DEG RETURN BENDS | CAPS |
|---|---|---|---|---|---|---|---|
| NPS | ID at End (1), (3), (4) | OD at Bevel (1), (2) | Centre-to- Centre O | Overall Length H | Centre -to- End Dimension A, B, C, M | Alignment of Ends U | Overall Length E |
| ½ to 2½ | 0.003 | 0.006 -0.003 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 3 to 3 ½ | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 4 | 0.006 | 0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.012 |
| 5 to 8 | 0.006 | 0.009 -0.006 | 0.025 | 0.006 | 0.006 | 0.003 | 0.025 |
| 10 to 18 | 0.012 | 0.016 -0.012 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 20 to 24 | 0.019 | 0.025 -0.019 | 0.038 | 0.009 | 0.009 | 0.006 | 0.025 |
| 26 to 30 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.012 | … | 0.038 |
| 32 to 48 | 0.019 | 0.025 -0.019 | … | 0.019 | 0.019 | … |
Inconel 617 pipe fittings offer several key advantages, making them ideal for high-temperature and corrosive environments. Their exceptional resistance to oxidation, carburization, and scaling ensures long-term durability, even in extreme conditions. The alloy maintains high strength and excellent creep resistance at temperatures up to 2000°F (1093°C), making it suitable for demanding industrial applications. Inconel 617 also provides superior resistance to high-temperature corrosion, ensuring reliability in the aerospace, power generation, and chemical industries. Additionally, it exhibits excellent weldability and fabricability, offering ease of installation and maintenance in complex systems.
|
Nominal
Pipe
Size |
45° Elbow |
90° Elbow |
OD |
180° Returns |
||||
|
(inch.) |
LR |
SR |
LR |
LR |
||||
|
Radius
(inch.) |
Center to Face
(inch.) |
Center to Face
(inch.0) |
Center to Face
(inch.0) |
(inch) |
(millimeter) |
Back to face
(inch.) |
Center to Center
(inch.) |
|
|
1/2 |
5/8 |
– |
1 1/2 |
0.0840 |
21.03 |
1 7/8 |
2 |
|
|
3/4 |
7/16 |
– |
1 1/8 |
1.0050 |
26.07 |
1 11/16 |
2 1/4 |
|
|
1 |
7/8 |
1 |
1 1/2 |
1.0315 |
33.04 |
2 3/16 |
3 |
|
|
1 1/4 |
1 |
1 1/4 |
1 7/8 |
1.0660 |
42.02 |
2 3/4 |
3 3/4 |
|
|
1 1/2 |
3 |
1 1/8 |
1 1/2 |
2 1/4 |
1.0900 |
48.03 |
3 1/4 |
4 1/2 |
|
2 |
4 |
1 3/8 |
2 |
3 |
2.0375 |
60.03 |
4 3/16 |
6 |
|
2 1/2 |
5 |
1 3/4 |
2 1/2 |
3 3/4 |
2.0875 |
73.00 |
5 3/16 |
7 1/2 |
|
3 |
6 |
2 |
3 |
4 1/2 |
3.0500 |
88.09 |
6 1/4 |
9 |
|
3 1/2 |
7 |
2 1/4 |
3 1/2 |
5 1/4 |
4.0000 |
101.06 |
7 1/4 |
10 1/2 |
|
4 |
8 |
2 1/2 |
4 |
6 |
4.0500 |
114.03 |
8 1/4 |
12 |
|
5 |
10 |
3 1/8 |
5 |
7 1/2 |
5.0563 |
141.03 |
10 5/16 |
15 |
|
6 |
12 |
3 3/4 |
6 |
9 |
6.0625 |
168.03 |
12 5/16 |
18 |
|
8 |
12 |
5 |
8 |
12 |
8.0625 |
219.01 |
16 5/16 |
24 |
|
10 |
15 |
6 1/4 |
10 |
15 |
10.0750 |
273.01 |
20 3/8 |
30 |
|
12 |
18 |
7 1/2 |
12 |
18 |
12.0750 |
323.09 |
24 3/8 |
36 |
Yes, custom sizes for Inconel 617 Pipe Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.
You’ll find Inconel 617 Pipe Fittings widely used in sectors like power generation, chemical processing, petrochemical, and aerospace. Their ability to perform reliably under high-pressure and high-temperature conditions makes them perfect for heat exchangers, gas turbines, and combustion chambers. Additionally, these fittings are essential in furnace hardware and waste treatment systems where oxidation resistance is vital. With their strength, durability, and resistance to environmental degradation, Inconel 617 Pipe Fittings are the go-to option for engineers and manufacturers in Midland, UK, who are looking for reliability and a long service life.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
