Zain Fittings, located in Surabaya, Indonesia, stands out as a leading manufacturer and supplier of **Alloy Steel F5 Forged Fittings** in **Midland, UK**. Renowned for their precision-engineered fittings, the company adheres to international quality and durability standards. These fittings are crafted to endure high pressure and temperature, making them perfect for tough industrial applications. With state-of-the-art manufacturing facilities and a talented workforce, Zain Fittings guarantees consistent performance, exceptional strength, and precise dimensions in every product. Their dedication to quality and customer satisfaction has built a solid reputation in the global piping components market.
| Specification : | ASTM A182 F5 Forged Fittings |
|---|---|
| Pressure Rating | Threaded Fittings = Class 2000, Class 3000, Class 6000 |
| Type Of Pipe systems | 45 Deg Elbow, Equal tee, Full Coupling, Reducing Tee, 90 Deg Elbow, Half Coupling, Street Elbow, Bull Plug, Boss, Union (Male/Female), Lateral Outlet, 45 Lateral Tee, Equal Cross, Pipe Cap, Branch Outlets, Swage Nipple. |
| Thread Connections | ASME B16.11 (Socket Welding and Threaded), MSS-SP-83 (Class Unions), ASME B16.3 (Malleable Iron Fittings), ASME B16.4 ( Gray Iron Fittings), ASME B16.39 (Malleable Iron Unions), ASME B16.34 (Valves — Flanged), ASME B16.39 (Malleable Iron Pipe Unions, 150#, 250#, Or 300#). |
| Standards | ASME B16.11 (American Standard) Fittings, Bs3799 Fittings, MSS SP 79 Fittings, JIS B2302 Fittings, MSS-SP-97 (Threadolet) Fittings, MSS-SP-83 (Union) Fittings, ASME B36.19 (Nipple) Fittings |
| Types Of Thread | NPT Fittings, BSPP Fittings, BSPT Fittings, PF Fittings, PT Fittings, MPT Fittings |
| Applications | Oil and Gas Chemical Power station Water Pipeline Noncritical Applications Fire Protection |
| Advantages Of | Simple Usage Easy installation Economic as cheaper |
| Size | Threaded Fittings = ½” – 4” |
**Alloy Steel F5 Forged Fittings** mainly consist of chromium (4–6%), molybdenum (0.4–0.6%), carbon, manganese, phosphorus, sulfur, and silicon. This unique blend boosts their strength at high temperatures and enhances their resistance to corrosion and oxidation. These fittings exhibit remarkable tensile strength, good yield properties, and outstanding hardness, making them perfect for high-pressure settings. They maintain stability and structural integrity even under extreme thermal stress, ensuring a long service life and reliability in critical industrial systems that require consistent mechanical performance.
| Gr | C | Mn | Si | S | P | Cr | Mo |
| ASTM A182 F5 Forged Fittings | 0.15 | 0.3 – 0.6 | 0.5 | 0.03 | 0.03 | 4 – 6 | 0.044 – 0.65 |
| Gr | Tensile Strength (Mpa) | Yield Strength (Mpa) | Elongation % |
| ASTM A182 F5 Forged Fittings | 275 | 485 | 20 |
**Alloy Steel F5 Forged Fittings** find extensive use in sectors like power generation, petrochemical processing, oil and gas, and refineries. Their excellent thermal resistance and durability make them ideal for high-pressure steam lines, heat exchangers, and boiler applications. Additionally, these fittings are utilized in chemical plants, shipbuilding, and industrial piping systems where strength and temperature tolerance are crucial. Their ability to perform reliably under extreme conditions makes them a top choice for systems that demand precision, corrosion resistance, and long-term operational stability.
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choose Alloy Steel F5 Forged Fittings from Zain Fittings for superior quality, exceptional corrosion resistance, and reliable performance in extreme conditions. We offer customized solutions backed by expert support and industry experience.
Alloy Steel F5 Forged Fittings offer numerous advantages, making them ideal for critical industrial applications. Their high chromium and molybdenum content provides excellent corrosion and oxidation resistance, ensuring durability in harsh environments. These fittings deliver exceptional strength and thermal stability, performing reliably in high-pressure and high-temperature conditions. The forged construction enhances their mechanical properties, ensuring secure, leak-proof connections. They are also resistant to wear and deformation, extending the lifespan of pipeline systems. Cost-effective and versatile, Alloy Steel F5 Forged Fittings are a preferred choice for industries like oil, gas, and power generation.
Yes, custom sizes for Alloy Steel F5 Forged Fittings are available at Zain Fittings. We offer tailored solutions to meet your specific requirements, ensuring optimal performance for your projects. For more information, please contact us at sales@zainfittings.id.
| STANDARD | UNS | WERKSTOFF NR. | Trade Name |
| ASTM A182 F5 Forged Fittings | K41545 | 1.7362 | 5Cr-1/2Mo |
| DN | NPS | Center to End NPT Elbow, NPT Tee, NPT Cross A | Center to End 45 Deg Elbow C | O.D. of Band H | Min. Wall Thick. G | Length of Thread. Minimum (1) | |||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | Class 2000 | Class 3000 | Class 6000 | B | L2 | ||
| 6 | 1/8 | 21 | 21 | 25 | 17 | 17 | 19 | 22 | 22 | 25 | 3.18 | 3.18 | 6.35 | 6.4 | 6.7 |
| 8 | 1/4 | 21 | 25 | 28 | 17 | 19 | 22 | 22 | 25 | 33 | 3.18 | 3.30 | 6.60 | 8.1 | 10.2 |
| 10 | 3/8 | 25 | 28 | 33 | 19 | 22 | 25 | 25 | 33 | 38 | 3.18 | 3.51 | 6.98 | 9.1 | 10.4 |
| 15 | 1/2 | 28 | 33 | 38 | 22 | 25 | 28 | 33 | 38 | 46 | 3.18 | 4.09 | 8.15 | 10.9 | 13.6 |
| 20 | 3/4 | 33 | 38 | 44 | 25 | 28 | 33 | 38 | 46 | 56 | 3.18 | 4.32 | 8.53 | 12.7 | 13.9 |
| 25 | 1 | 38 | 44 | 51 | 28 | 33 | 35 | 46 | 56 | 62 | 3.68 | 4.98 | 9.93 | 14.7 | 17.3 |
| 32 | 1-1/4 | 44 | 51 | 60 | 33 | 35 | 43 | 56 | 62 | 75 | 3.89 | 5.28 | 10.59 | 17.0 | 18.0 |
| 40 | 1-1/2 | 51 | 60 | 64 | 35 | 43 | 44 | 62 | 75 | 84 | 4.01 | 5.56 | 11.07 | 17.8 | 18.4 |
| 50 | 2 | 60 | 64 | 83 | 43 | 44 | 52 | 75 | 86 | 102 | 4.27 | 7.14 | 12.09 | 19.0 | 19.2 |
| 65 | 2-1/2 | 76 | 83 | 95 | 52 | 52 | 64 | 92 | 102 | 121 | 5.61 | 7.65 | 15.29 | 23.6 | 28.9 |
| 85 | 3 | 86 | 95 | 106 | 64 | 64 | 79 | 109 | 121 | 146 | 5.99 | 8.84 | 16.64 | 25.9 | 30.5 |
| 100 | 4 | 106 | 114 | 114 | 79 | 79 | 79 | 146 | 152 | 152 | 6.55 | 11.18 | 18.67 | 27.7 | 33.0 |
| Normal Pipe Size | A | B | QTY | Weight In KG |
|---|---|---|---|---|
| ¼ | 0.81 | 0.88 | 160 | 0.20 |
| ⁄ | 0.97 | 1.00 | 130 | 0.26 |
| ½ | 1.12 | 1.31 | 100 | 0.57 |
| ¾ | 1.31 | 1.5 | 75 | 0.71 |
| 1 | 1.5 | 1.81 | 40 | 1.08 |
| 1 ¼ | 1.75 | 2.19 | 25 | 1.68 |
| 1 ½ | 2.00 | 2.44 | 18 | 2.38 |
| 2 | 2.38 | 2.97 | 10 | 3.55 |
| 2 ½ | 3.00 | 3.62 | 4 | 6.22 |
| 3 | 3.38 | 4.31 | 2 | 10.36 |
| 4 | 4.19 | 5.75 | 1 | 23.91 |
Alloy Steel F5 Forged Fittings are widely used in industries requiring robust and reliable pipeline systems. Their excellent resistance to corrosion, oxidation, and high temperatures makes them ideal for applications in oil and gas, petrochemical, power generation, and chemical processing industries. Common uses include steam boilers, heat exchangers, and refinery equipment operating under extreme conditions. These fittings are also suitable for industrial pipelines in water treatment plants and offshore drilling operations, providing secure, leak-proof connections and enhancing the efficiency and safety of critical systems.
Get in touch with one of our Technical Sales Representatives to request a quote or get answers to any questions you may have.
